Kia Picanto (JA): Rear Door / Rear Door Side Weatherstrip
Repair procedures
| Replacement |
| 1. | Loosen the rear door checker (B) mounting bolt.
|
| 2. | Detach the clips, and remove the rear door side weatherstrip (A).
|
| 3. | Install in the reverse order of removal.
|
Repair procedures Replacement 1.Remove the rear door trim. (Refer to Rear Door - "Rear Door Trim") 2.Remove the rear door belt outside weatherstrip (A) after loosening the mounting screw.
Components and components location Components [6:4 folding type] 1. Rear seat cushion pad 2. Rear seat cushion covering 3. Rear seat back covering 4.
