Schematic diagrams
Schematic Diagram

Repair procedures
Inspection
1.
After disconnecting the vapor hose from the PCV valve, remove the PCV valve.
2.
Reconnect the PCV valve to the vapor hose.
3.
Run the engine at idle, then put a finger over the open end of the PCV valve and make sure that intake manifold vacuum can be felt.

The plunger inside the PCV valve will move back and forth at vacuum.

4.
If vacuum is not felt, inspect the PCV operation. If it is operating correctly, clean or replace the vapor hose.
Emission Control System
Specifications Specifications Purge Control Solenoid Valve (PCSV) ▷ Specification Item Specification Coil Resistance (Ω) 18. ...

Positive Crankcase Ventilation (PCV) Valve
Description and operation Operation Principle Repair procedures Removal 1. Disconnect the vapor hose (A). 2. Remove the PCV valve (B). PCV valve : 1. ...
