Kia Picanto (JA): Your vehicle at a glance / Exterior overview
1. Hood
2. Head lamp (Features of your vehicle)
Head lamp (Maintenance)
3. Front fog lamp (Features of your vehicle)
Front fog lamp (Maintenance)
4. DRL lamp (Features of your vehicle)
5. Wheel and tire
6. Outside rearview mirror
7. Sunroof
8. Front windshield wiper blades (Features of your vehicle)
9. Windows
10. Radar type Autonomous Emergency Braking
1. Door locks
2. Fuel filler lid
3. Rear combination lamp (Maintenance)
4. High mounted stop lamp (Maintenance)
5. Tailgate
6. Antenna
7. Rearview camera
8. Rear parking assist system
9. Back up lamp (Maintenance)
10. Rear window wiper blade (Features of your vehicle)
