Kia Picanto: Automatic climate control system / Air Conditioning refrigerant label

Kia Picanto JA 2017-2024 Owner's Manual / Features of your vehicle / Automatic climate control system / Air Conditioning refrigerant label

Each symbols and specification on air conditioning refrigerant label means as below ;

1. Classification of refrigerant

2. Amount of refrigerant

3. Classification of Compressor lubricant

You can find out which air conditioning refrigerant is applied your vehicle at the label inside of the engine room. Refer to “Refrigerant label” on page 9-19.

Climate control air filter

A : Outside air B : Recirculated air C : Climate control air filter D : Blower E : Evaporator core F : Heater core The climate control air filter installed behind the glove box filters ...

Checking the amount of air conditioner refrigerant and compressor lubricant

When the amount of refrigerant is low, the performance of the air conditioning is reduced. Overfilling also has a bad influence on the air conditioning system. Therefore, if abnormal operation ...
