Kia Picanto: Manual climate control system / Air Conditioning refrigerant label

Kia Picanto JA 2017-2025 Owner's Manual / Features of your vehicle / Manual climate control system / Air Conditioning refrigerant label

Each symbols and specification on air conditioning refrigerant label means as below ;

1. Classification of refrigerant

2. Amount of refrigerant

3. Classification of Compressor lubricant

You can find out which air conditioning refrigerant is applied your vehicle at the label inside of the engine room. Refer to “Refrigerant label” on page 9-19.
